Explosion Proof Pressure Transmitter Pressure Sensor Pressure Transducer Oil Gas Fuel Pressure Measurement Non-hazardous area

$46.00 $39.80

Accuracy: 0.5%

0.5%
0.25%

Output: 4-20mA

4-20mA
0-5V
0-10V
RS485

Display: None

None
LCD
LED

Description


Description

Add to WishlistCompare

amazon paymentsamerican expressapple paybitcoindankortdiners clubdiscoverdogecoindwollaforbrugsforeningeninteracgoogle payjcbklarnaklarna-pay-laterlitecoinmaestromasterpaypalshopify paysofortvisa
Ask a Question
SKU:
Availability: In Stock Pre order Out of stock
Categories: Instruments Pressure Measurement
Tags: Pressure sensor Pressure transducer Pressure transmitter
Description

                • Essential Specifications:
                  Measuring Medium: Gas; Liquid
                  Sensor Core: diffusion silicon
                  Power Supply: 12~36V DC
                  Measuring Range: -0.1MPa~60MPa (Customizable)
                  Measurement Accuacy:±0.5%F.S; ±0.25% (Optional)
                  Output Signal: 4-20mA, 0-5V, 0-10V, RS485 (Selectable)
                  Working Temperature: -20~70℃; 200℃ (Optional)
                  Pressure Overload: 150%F.S
                  Long-term Stability: ±0.1%F.S/ year
                  On-site Display: None; LED; LCD
                  Process Connection: M20*1.5, 1/2" NPT, G 1/2,
                                Tri-clamp, single flange (Customizable)
                  Electrical Interface: M20*1.5
                  Waterproof Grade: IP66
                  Explosionproof Grade: Ex db IIC T6


                  • Highlight Points Before Order:
                    Measuring Medium
                    Output Signal
                    Accuracy Class
                    Medium Temperature
                    Process Connection
                    On-site Display



Additional Information
Accuracy

0.5%, 0.25%
Output

4-20mA, 0-5V, 0-10V, RS485
Display

None, LCD, LED
