Liquid Turbine Flow Meter Gasoline Vegetable Oil Flow Measurement Sanitary Hygeian Flowmeter Low Viscosity Liquids Flow Measurement

$78.00

Display & Output: No display+Pulse output

No display+Pulse output
4-20mA no display
LCD display+4-20mA

Description


Description

Add to WishlistCompare

amazon paymentsamerican expressapple paybitcoindankortdiners clubdiscoverdogecoindwollaforbrugsforeningeninteracgoogle payjcbklarnaklarna-pay-laterlitecoinmaestromasterpaypalshopify paysofortvisa
Ask a Question
SKU:
Availability: In Stock Pre order Out of stock
Categories: Flow Measurement Instruments
Tags: Flow Meter Flow Transmitter Flowmeter Liquid Flow Oil flow Water Flow
Description

            • Essential Specifications:

              Measuring Medium: Most of low viscosity liquids (normally lower than 5*10^-6 ㎡/s)
              Power Supply: 24V DC; 3.6V DC battery (optional)
              Nominal Diameter: DN4~DN200
              Nominal Pressure: 0.6MPa~6.3MPa (related to pipe size and materials)
              Range Ratio: 1: 10; 1: 15; 1:20
              Measurement Accuacy:±1%F.S; ±0.5%F.S; ±0.2%F.S (special customization)
              Output Signal: Pulse; 4-20mA; RS485; HART
              Working Temperature: medium, -20~120℃ (higher temperature is customizable); convertor, -20~60℃
              Wetted Material: SS304; SS316; PTFE; others
              On-site Display: None; integrated LCD
              Process Connection: Flange, Thread; Tri-clamp
              Electrical Interface: Direct outlet; M20*1.5
              Waterproof Grade: IP65
              Explosionproof Grade: Ex ia IIC T6









            • Highlight Points Before Order:

              Measuring Medium
              Pipe Diameter
              Flow Range
              Wetted Meterial
              Output Signal
              Flowmeter Structure
              Process Connection
              Accuracy Class
Additional Information
Display & Output

No display+Pulse output, 4-20mA no display, LCD display+4-20mA
