Submersible Level Transmitter Hydrostatic Level Meter Level Sensor Water Level Measurement Integrated Level Submerged Level
Description
-
-
-
-
-
-
Essential Specifications:
Measuring Medium: Non-corrosive water
Power Supply: 12~36V DC; 5V DC (Optional)
Measuring Range: 0~500m
Measurement Accuacy:±0.5%F.S; ±0.3%F.S (Optional)
Output Signal: 4-20mA, 0-5V, 0-10V, RS485 (Selectable)
Working Temperature: -20~50℃
Long-term Stability: ±0.2%F.S/ year
On-site Display: None; LED; LCD
Process Connection: cable only; G1 thread; other threads > 1"
Electrical Interface: cable only; M20*1.5
Waterproof Grade: IP68 for cable type; IP65 for on-site display type
Sensor Housing: SS 304; SS 316
Cable Material: Polyurethane, 2 core or 4 core shielded cable
-
Highlight Points Before Order:
Measuring Medium
Measuring Range
Cable Length
Output Signal
Accuracy Class
Housing Material
Process Connection
Construction Type
On-site Display
-
-
-
-
-
Additional Information
| Construction Type |
Integrated, Split |
|---|---|
| Output Signal |
4-20mA, 0-5V, 0-10V, RS485 |
Submersible Level Transmitter Hydrostatic Level Meter Level Sensor Water Level Measurement Integrated Level Submerged Level
$35.80
